AlphaDisc™
Disc Filter ​

Lean & Mean Filtration Machine

AlphaDisc™ gives you ultimate irrigation system protection thanks to a combination of precise depth filtration, high dirt-holding capacity, and a unique easy-to-scale modular design that adapts with your changing flow rate or water quality needs. AlphaDisc™ also features a smart controller providing performance data at your fingertips.

AlphaDisc™ prevents clogging and partial clogging to ensure system longevity and uniformly irrigated crops, so you can enjoy better ROI, cost-saving, and peace of mind.

AlphaDisc™ - disc filter
153549

Make sure you’re making the right decision:​

Product Advantages

  • Superb efficiency - Unique and improved disc design with precise filtration grade through all depths of the disc ensuring better clogging protection
  • Industry leader - High dirt-holding capacity and high filtration volume and area, coupled with lowest head loss in the industry, ensures higher particles capture, fewer backflush cycles, and less downstream disruption
  • Hyper modular - Unique modular design offers easy scalability as your needs evolve
  • Cost-effective - Low backflush flow rate and low head loss result in a significantly more profitable irrigation system
  • Innovative - AlphaDisc™ smart controller with “always on” access to filtration data; IP65 rating
  • Smaller footprint - Vertical installation for a well-designed, more cost-effective irrigation room
  • Multiple configurations - Inline, online and angle configuration (single unit), Dual, Trio and Alphapollo; easily adapted to any system configurations
  • Made to last - Durable and long-lasting product made from anticorrosive materials

Applications:

  • For surface water containing algae and other organic materials such as reservoirs, canals, rivers and wastewater applications
  • For well water containing light sand (<3 ppm) and other contaminants
  • Areas with or without electricity
  • For residential, commercial, industrial, parks, municipal and non-potable water sources
  • Greenhouses and Nurseries
  • Waste water applications
  • For industrial use with recycled water or water discharged from a plant.
  • Can be use as primary or secondary treated effluent.
  • Residential and multi-family developments
  • Commercial landscapes, institutional parks, sports fields
  • Golf courses
  • Large landscape installations

Specifications

  • Maximum Flow rate – Different models from 40 GPM up to very high flow rates
  • Minimum Flow for Backflush:
    • Short spines – 31 GPM @ 22 PSI per spine
    • Long (XL) spines – 57 GPM @ 22 PSI per spine.
  • Maximum Operating Water Pressure:  145 psi
  • Minimum Pressure for Backflush: 22 psi
  • Inlet / Outlet diameter:
    • Single – 3”
    • Single XL – 3” or 4”
    • Dual XL – 6”
    • Trio XL – 8”
    • Alphapollo – 10” or 12”
  • Flush Port: 3" Grooved or Flange
  • Minimum Allowable pH: 5
  • Max. Allowable Temperature: 158° F

"AlphaDisc allows for a multi-phase investment, making budgeting more manageable than ever. This is especially important for scalable projects. Compared with old-style filters, which require the grower to upfront all the costs on day one, our AlphaDisc filtration system eases the financial stress and provides more flexibility and possibilities for scaling."

READ MORE

Frequently asked questions​

Product Sheets & Manuals

Product Sheets

Product Sheets

Manuals

Manuals

AlphaDisc CAD Drawings

3"

3"

4"

4"

6"

6"

8"

8"
