Dynamic Air Vent is a unique air vent that operates without a float and utilizes the rolling diaphragm principle. This allows slow and gradual air discharge preventing water hammer.

PRODUCT OVERVIEW
Overview

Why Dynamic Air Vent

  • Rolling diaphragm principle allows air to be discharged in a controlled and gradual manner preventing slam and surges.
  • Reacts very quickly to vacuum surges by intaking large amounts of air - three times more air than other vents.
  • Air vent is normally closed when the line is not operating preventing debris and contaminants from entering the pipeline.
  • Light-weight and small for easy installation with simple and reliable operation.
  • Built-in outlet connection for surplus water drainage.
  • Corrosion-resistant composite materials.

Product Advantages

  • Air vent is normally closed when the line is not operating preventing debris and contaminants from entering the pipeline.
  • Light-weight and small for easy installation with simple and reliable operation.
  • Built-in outlet connection for surplus water drainage.
  • Corrosion-resistant composite materials.
  • Installation on irrigation systems with any diameter pipeline when the slope is greater than 2 - 3%
  • Installation on irrigation systems with 8” or great diameter pipelines
  • For discharge of air at pump and filtration stations, along mains and at the end of mainlines
  • At high points in the pipe network or upstream of manifolds

Applications

  • Installation on irrigation systems with any diameter pipeline when the slope is greater than 2 – 3%
  • Installation on irrigation systems with 8” or great diameter pipelines
  • For discharge of air at pump and filtration stations, along mains and at the end of mainlines
  • At high points in the pipe network or upstream of manifolds

Specifications

Specifications

  • Maximum operating pressure: 150 psi
  • Maximum working temperature: 140° F
  • Available size: 2” a 3″ NPT Male Threaded

Materials

  • Body: Reinforced Nylon
  • Drainage Elbow: Polypropylene
  • Rolling Seal: EPDM Rubber
  • O-Ring: BUNA-N
