Landscape & Turf

Self-Piercing Emitters

Pressure compensating, self-flushing emitters with a check valve and self-piercing barb for easy installation.

Why Self-Piercing Emitters

  • Self-Piercing Barb
    Easy to install, no tools required. Optional insertion tool available.
  • 1.74 psi Internal Check Valve
    Helps prevent low emitter drainage holding back up to a 3.9′ column of water. Can be used with Techline HCVXR and CV Dripline.

Product Advantages

  • Anti-Siphon Operation
    Prevents contaminants from being drawn into the emitter.
  • Pressure Compensating
    Delivers the same flow from 10.15 to 58 psi.
  • Self-Cleaning Action
    Exclusive TurboNet® flow path design regulates flow and provides continuous self-cleaning action during operation.


  • For use with blank polyethylene tubing, Techline® HCVXR, CV, DL and RW
  • Install on-surface or subsurface
  • Wide-spaced plantings
  • Tree planting
  • Hanging baskets
  • Flower boxes
  • Planters or pots


  • Flow rates: 0.5, 1.0 and 2.0 GPH
  • Pressure compensation range: 10.15 to 58 psi
  • Maximum pressure: 58 psi
  • Uses 0.160” x 0.220” micro-tubing (Model EDTUBE – in black or white)
  • Barb size: Inlet 0.160” – 0.170” Outlet 0.160”
  • Recommended minimum filtration: 120 mesh
