COMBINATION MASTER VALVE AND WATER METER FLOW SENSOR

A combination water meter and hydraulic valve in a single unit saving space and installation costs. The double-chambered valve is specially designed for high-pressure operation. Addition of pilot or solenoid valves enables remote and/or automatic hydraulic commands. No straight pipe length is required upstream or downstream of the globe configuration hydrometers making them ideal for tight installations. Available in globe configuration and a large variety of sizes.

Product Advantages

  • Globe Configuration With Built-In Straightening Vane: Requires no straight pipe installation – saving space.
  • ± 2% Accuracy Across Flow Ranges: No more false alarms.
  • Rugged, Heavy Duty Construction: Cast Iron with corrosion-resistant coating.
  • Registers Are Stainless Steel/Composite Encapsulated: Guaranteed against fogging due to moisture.
  • Double-Chambered Valve: Provides quick acting and positive opening and closing.
  • Sub Metering: Meter dedicated to landscape irrigation water.

Applications

  • For commercial, institutional and sports field irrigation applications
  • Ideal for retro-fits
  • Designed for high pressure, remote operated applications
  • Water meter can be used to communicate with irrigation controllers and central control units.
  • Valve can function as a remote master valve for automated operation.

Specifications

  • Sizes: 1 ½”, 2”, 3”, 4”, 6” and 8”
  • Maximum working pressure:
    Manual Electric – 235 psi
    Pressure Reducing Manual Electric – 140 psi
  • Body: Cast iron, polyester coated
  • Valve diaphragm: reinforced natural rubber
  • Pilot option: manual electric
  • End Connections:
    1 1/2″ – male pipe thread
    2″ – female pipe thread
    3″, 4″, 6″, 8″ – flanged
  • Flanges: drilled according to ANSI specification
  • Standards: EEC approval (class A)
  • Installation of a continuous acting air vent before the Hydrometer is highly recommended for accurate flow readings
