Reliable and durable control and master valves.

Product Overview
Overview

Why Series 80 Nylon Control Valves

  • Easiest Operation And Lowest Maintenance Costs
    New and improved manual selector allows for hassle-free internal bleed without manipulating the position of the solenoid. Innovative labyrinth inlet eliminates the need for internal filters, reducing service costs for end users, contractors and Distributors.
  • Flow Control Standard On All Models
    Manual zone control from fully closed to maximum capacity at no extra charge
  • High Efficiency, Longer Lasting Solenoid
    Inrush and holding current are 50-60% lower than the industry average which allows the industry’s longest wire runs from valve to controller. Low sensitivity to dirt and voltage fluctuations.

Product Advantages

  • Proven Reliability with Reclaimed Water
    Over a decade of field-proven, consistent performance under the harshest water conditions. Durable and corrosion-resistant materials.
  • 2-Wire System Compatibility
    Works with all major manufacturer 2-Wire control systems.

Applications

  • Residential or commercial landscape irrigation applications
  • For mild corrosive and mild acidity levels in the water
  • For remote control, master valve, automated operations
  • Reclaimed/reuse applications including municipally treated reclaimed water designated for irrigation

Specifications

  • Recommended flow range:
    ¾” – 0.01 to 26 GPM
    1” – 0.01 to 44 GPM
    1 ½” – 0.25 to 110 GPM
    2“ – 0.25 to 176 GPM
  • Minimum operating pressure: 7 psi
  • Maximum operating pressure: 150 psi
  • Water temperature: up to 140° F
  • Improved manual selector and encapsulated solenoid available on 3/4” and 1“ models only
  • 24VAC solenoid standard +/- 10% voltage
  • Solenoid inrush current: 0.220A
  • Solenoid holding current: 0.095A
  • Optional Solenoids: 24VDC, 12VDC, 12VDC-latching and 120VAC
  • Integral stainless steel EasyClean® filter for 1½” and 2” models only
  • Adjustable pressure regulator option available: 1.5″ and 2″ model
    • Normally Closed Option: 3/4″ – 2″
    • Normally Open Option: 1 1/2″ – 2″
