Netafim Water Meters are reliable, precision quality flow measuring instruments. The baked, powder-coated epoxy surface resists corrosive conditions. Only one moving part, the impeller is in contact with water for minimum wear and utmost reliability. All flow meters can be installed in several positions to meet the specific application needs. Water meter sizes 1″ and 1 1/2″ sizes have a maximum working pressure of 145 psi. Sizes 2″, 3″, and 4″ have a maximum working pressure of 230 psi.
Provide precise measurement of flow with double-beam ultrasonic sensors. There is no impeller or moving parts in the flow path. A multi-line readout screen provides complete flow and volume information instantaneously and the 9 digit display is easy to read at a glance. With flow ranges from 1 to 5,500 GPM and 2" to 12" sizes, the Octave Ultrasonic Water Meter provides highly accurate flow readings.
WST Water Meters use a double magnetic transmission to drive the register and this unique design enables the meter to handle high loads of sand since only the impeller is in contact with the water. Transmission gears are located in a sealed, dry compartment which has no contact with the water. The impeller, located in the center of the flow, allows for very accurate measurements over a wide range of flows. Available in 3″, 4″, 6″, 8″, 10″ and 12″ sizes.
The WMR contains an in-line axial turbine which allows foreign matter to pass through the meter without clogging. Wide clearances in the measuring chamber and negligible area of contact between static and moving parts are the main reasons for the high reliability of this design even in hard water. Available in 3/4″, 1″, 1 1/2″ and 2″ sizes.
Netafim offers Fertilizer Meters with a polypropylene or PVC body. The polypropylene fertilizer meter is small, lightweight and delivers a high level of accuracy. It’s compact size, corrosion-resistant plastic components are ideal for fertilizer control in automated irrigation systems. Available in ¾” size.
